Autoprint BJD 42

AUTOPRINT BJD 42

The BSD 42 / BJD 42 banding machine is designed for efficient, fast, and user-friendly bundling operations. It supports both paper and film banding, ensuring flexibility for different packaging needs. With minimal material usage and no warm-up time required, it improves productivity while reducing operational costs. The machine delivers damage-free bundling results and allows precise temperature and tension adjustments for secure and high-quality output. Its intuitive touch screen interface makes operation simple, allowing a single operator to handle the entire process efficiently.

View Brochure

Features

Technical Specifications

Model	BJD 42
Bundling Size (Maximum)	400 mm W x 200 mm H / 15.7" x 7.8"
Bundling Size (Minimum)	30 mm W x 10 mm H / 1.18" x 0.39"
Bundling Speed	Up to 26 bundles per minute
Bundling Tension	5 - 20N (1N = 0.1 kgf)
Tape Width (Standard Size)	30 mm / 1.18"
Tape Length (Paper Material)	600 m / 1968 ft
Tape Length (Film Material)	750 m / 2460 ft
Power	220 watts
Power Supply	220 V, 50 Hz (Single Phase)
Net Weight (Kg)	49
Physical Dimensions (L x W x H)	570 x 400 x 1110 mm
