Technical Specifications
| Model | SODLC 36 |
|---|---|
| Max. laminating width | 360mm |
| Operating speed | 14 meters / minute |
| Paper thickness | 125~350 gsm |
| Laminating temperature | 90 - 110 degree (Normal) |
| Total Power | 2.2 KW |
| Temperature control | Upper / lower temperature are controlled separately |
| Upper heating roll | Steel Roll (Standard) |
| Lower heating roll | Rubber roll |
| Control panel | 7" Touch Panel |
| Feeding mode | Suction Feeding |
| Overlap | Yes |
| Auto Bursting | Yes |
| Slitting function | Yes |
| Anti-curling function | Yes |
| Loading capacity | 150mm |
| Optional | Lower / Upper Rewinder |
| Machine Size(LxWxH cm) | 185x75x147 |
