Features
- Manual Overlap feed, simple and easy operation
- Pneumatic Pressure Machine for better lamination results
- LED System Control Panel
- Adjustable Paper Side guides at feed end
- Overlap mode on/off for Overlap device
- Paper length / Overlap length can be varied by just programming
- Temperature Settings Control & Current temperature displays
- Heating Process Indicator lamp
- Anti-curling device to de-curl the sheets
- Paper Separation Sensor
- Speed Adjustment Knob
- Film Holder unit equipped with Perforation and Slitting wheel
- Angle of the Paper Receiving Tray can be varied
- Safety cover
- Lesser Make Ready Time
- Less Power Consumption
Technical Specifications
Lamination with Auto Cut | Double Side |
Max. Laminating Width | 370 mm |
Unwinder Diameter | 300 mm (max), Core Dia 1 and 3 |
Operating Speed | 13 metres/minute |
Paper Thickness | 125 – 350 gsm |
Laminating Temperature | 90 – 110°C (manual) |
Heater Warm Up Time | 5 minutes |
Total Power | 1.6 Kw |
Temperature Control | Upper/lower (optional) |
Upper Heating Roll | Steel |
Lower Heating Roll | Rubber Roll |
Control Panel | Digital LED System |
Feeding System | Manual |
Overlap Feeding Function | Yes |
Bussing Function | Yes (Auto Separation) |
Slitting Function | Yes |
Anti-Curling Function | Yes |
Conveyor Belt | Yes |
Power Supply | 220V 50 Hz (Single Phase) |
Dimensions (L x W x H) | 100 x 61 x 125 cm |
